The 7050 Pick & Place system is used to handle small parts. Equipped with a pressure regulator and pressure gauge, the vacuum-suck function can be adjusted to the components accordingly.
____________________________________________________________________________________________________________________
A foot switch activates the system and the vacuum probe can be used to raise and lower components.
The TP-50 shows its strengths especially with low-viscosity materials such as acrylates, anaerobic adhesives, oils, solvents, fluxes or aqueous solutions.
______________________________________________________________________________________________________________________
The digitally installed air-pressure control-circuit in this system allows for a finer dispense process by a factor 100 (in comparison to purely electro-pneumatic models).
_________________________________________________________________________________________________________________
The digitally installed air-pressure control-circuit in this system allows for a finer dispense process by a factor 100 (in comparison to purely electro-pneumatic models).
__________________________________________________________________________________________________________________
Some Like it HOT, most do not...
The Latest Advancements in Adhesives for Thermal Management
Join us for a webinar on Tuesday, June 11, 2019
The Piezobrush® has been conceived to be an efficient handheld unit. The plasma handheld device is also very suitable for being used in professional model making, in laboratories and the manual assembly of small lots. Glueing of synthetic materials becomes easier due to surface activation resulting from the impact of cold plasma.
This electro-pneumatic system allows a precise adjustment with the integrated digital display. The timer function can be set quickly from 0.005 to 9.999s
The “dam & fill” process with two materials is mainly used in cases where a component needs to be protected with an optically-transparent encapsulant or if a conventional glob-top material is too viscous to flow around and underneath fine wires. Optically transparent encapsulants usually have a low viscosity. A dam is therefore applied around the component first to prevent the potting material from flowing all over the substrate.
